AD Changes Dashboard

The AD Changes dashboard contains the following cards:

AD Changes Dashboard

  • Changes by Type – Breakdown of changes that have been recorded in the specified timeframe by event type. See the Graph Card Features topic for additional information.
  • Successful/Blocked Events – Breakdown of changes that have been recorded in the specified timeframe by successful/failed/blocked status. See the Graph Card Features topic for additional information.
  • Changes by Domain – Breakdown of changes that have been recorded in the specified timeframe by domain. See the Graph Card Features topic for additional information.
  • Top Client IPs – Displays up to the top five (5) client IP addresses related to events that have been recorded in the specified timeframe
  • Top Perpetrators – Displays up to the top five (5) perpetrator usernames related to events that have been recorded in the specified timeframe
  • Change Details – Tabular format of all Active Directory change events that have been recorded in the specified timeframe. See the Table Card Features topic for additional information.

The time interval is identified in the upper-right corner with the Start and End boxes. This is set by default to the past three (3) hours. To search within a different interval, either manually type the desired date and time or use the calendar buttons to set the desired date and time interval. Then click Search to refresh the card data.

When a search using a time interval longer than twelve (12) hours is instigated, the database query is broken into multiple mini-queries. This will result in a visible reset of the dashboard display at the end of each mini-query until all data for the selected time interval has been retrieved.
