6.Broken Inheritance > AD_BrokenInheritance Job

The AD_BrokenInheritance Job reports on all locations within Active Directory where inheritance is broken within the targeted domains.

6.Broken Inheritance Job Group in the Jobs Tree

The AD_BrokenInheritance Job is located in the 6.Broken Inheritance Job Group.

Analysis Tasks for the AD_BrokenInheritance Job​

Navigate to the Active Directory Permissions Analyzer > 6.BrokenInheritance > AD_BrokenInheritance > Configure node and select Analysis to view the analysis tasks.

CAUTION: Do not modify or deselect the selected analysis tasks. The analysis tasks are preconfigured for this job.

Analysis Tasks for the AD_BrokenInheritance Job

The default analysis tasks are:

  • Broken Inheritance Details – Creates the SA_AD_BrokenInheritance_Details table accessible under the job’s Results node
  • Broken Inheritance Summary – Creates an interim processing table in the database for use by downstream analysis and report generation

In addition to the tables and views created by the analysis tasks, the AD_BrokenInheritance Job produces the following pre-configured report.

ReportDescriptionDefault TagsReport Elements
Broken Inheritance by DomainThis report highlights instances of broken inheritance on Active Directory objects. This information is summarized by domain.NoneThis report is comprised of three elements: - Bar Chart – Displays broken inheritance by domain - Table – Provides summary of broken inheritance by OU - Table – Provides details on broken inheritance
