.Active Directory Inventory Solution

Active Directory (AD) acts as the central nervous system of any Microsoft environment and plays a vital role in granting access to resources such as Exchange, File Systems, SharePoint, and SQL Server. The .Active Directory Inventory Solution is designed to provide essential user, group membership, and computer details from the targeted domains to many Access Analyzer built-in solutions. Key information includes user status, user attributes, and group membership. The collected data is accessed by other Access Analyzer solutions and the Netwrix Access Information Center for analysis.

NOTE: This solution is required for using the Access Information Center.

This topic covers information on using the ADInventory Data Collector and the .Active Directory Inventory Job Group.

Supported Platforms

  • Windows 2003 Forest level or higher

Permissions

  • Read access to directory tree

  • List Contents & Read Property on the Deleted Objects Container

    NOTE: See the Microsoft Searching for Deleted Objects article and the Microsoft Dsacls article for additional information.

Ports

  • TCP 389
  • TCP 135-139
  • Randomly allocated high TCP ports

Location

The .Active Directory Inventory Solution is a core component of all Access Analyzer installations. Typically this solution is instantiated during installation, but it can be installed from the Instant Job Wizard. Once it has been installed into the Jobs tree, navigate to the solution: Jobs > .Active Directory Inventory. This group has been named in such a way to keep it at the top of the Jobs tree.

Jobs​

This Job Group is comprised of three jobs that collect, analyze, and report on data. The data collection is conducted by the ADInventory Data Collector. See the Standard Reference Tables & Views for the ADInventory Data Collector topic for database table information.

.Active Directory Inventory Solution Overview page

The .Active Directory Inventory Solution has the following jobs:

  • 1-AD_Scan Job – Collects data and generates the standard reference tables and views
  • 2-AD_Changes Job – Analyzes the collected data to track and alert on changes within all scanned domains that occurred since the last scan
  • 3-AD_Exceptions Job – Analyzes the collected data to identify security and provisioning concerns, such as circular nesting and stale membership
